The ITALFORNI TEKNO is an electric deck oven for pizza and pastry with a refractory baking floor, separate floor and ceiling power and a maximum of 450°C (842°F). TEKNO 1 has a single deck for 4 or 6 pizzas of 30 cm (11.8 in); TEKNO 2 stacks two decks, up to 9 + 9 pizzas of 35 cm (13.8 in), in stainless steel or rustic finish.
Key Features
- Refractory floor, armoured elements: A high-performance refractory floor with stainless steel armoured elements above and below gives an even, crisp bake.
- Floor and ceiling set separately: P-Regulation controls each chamber's floor and ceiling power on an electromechanical panel; digital control and Hyper P-Heating are optional.
- Moisture and ventilation: A vapour discharge and integrated hood module are standard; a hood motor kit is optional.
- Easy loading: Tempered-glass door on a counter-balanced hinge, with Lighting Plus halogen chamber lighting.
Specifications
TEKNO 1 (single deck)
| Specification | T1A | T1B |
|---|---|---|
| Pizzas | 4 at Ø 30 cm | 6 at Ø 30 cm |
| Baking pans 60 × 40 cm | 1 | 2 |
| Chamber, internal (H × W × D) | 15 × 61 × 62 cm (5.9 × 24 × 24.4 in) | 15 × 61 × 92 cm (5.9 × 24 × 36.2 in) |
| External dimensions (H × W × D) | 46 × 85 × 95 cm (18.1 × 33.5 × 37.4 in) | 46 × 85 × 125 cm (18.1 × 33.5 × 49.2 in) |
| Weight | 76 kg (168 lb) | 110 kg (243 lb) |
| Electrical supply | 400 V / 3 ph / 50-60 Hz | 400 V / 3 ph / 50-60 Hz |
| Power | 4 kW max; 2 kW/h average | 6 kW max; 3 kW/h average |
| Current draw | 6 A | 9 A |
| Temperature range | 0 to 450°C (32 to 842°F) | 0 to 450°C (32 to 842°F) |
TEKNO 2 (two decks)
| Specification | T2A | T2B | T2C | T2E | T2F |
|---|---|---|---|---|---|
| Pizzas | 4 + 4 at Ø 30 cm | 6 + 6 at Ø 30 cm | 6 + 6 at Ø 35 cm | 6 + 6 at Ø 35 cm | 9 + 9 at Ø 35 cm |
| Baking pans 60 × 40 cm | 1 + 1 | 2 + 2 | 2 + 2 | 2 + 2 | 4 + 4 |
| Chamber, internal (H × W × D) | 15+15 × 61 × 62 cm (5.9 + 5.9 × 24 × 24.4 in) | 15+15 × 61 × 92 cm (5.9 + 5.9 × 24 × 36.2 in) | 15+15 × 70 × 105 cm (5.9 + 5.9 × 27.6 × 41.3 in) | 15+15 × 105 × 70 cm (5.9 + 5.9 × 41.3 × 27.6 in) | 15+15 × 105 × 105 cm (5.9 + 5.9 × 41.3 × 41.3 in) |
| External dimensions (H × W × D) | 70 × 85 × 95 cm (27.6 × 33.5 × 37.4 in) | 70 × 85 × 125 cm (27.6 × 33.5 × 49.2 in) | 70 × 94 × 138 cm (27.6 × 37 × 54.3 in) | 70 × 129 × 103 cm (27.6 × 50.8 × 40.6 in) | 70 × 129 × 139 cm (27.6 × 50.8 × 54.7 in) |
| Weight | 120 kg (265 lb) | 160 kg (353 lb) | 190 kg (419 lb) | 190 kg (419 lb) | 220 kg (485 lb) |
| Electrical supply | 400 V / 3 ph / 50-60 Hz | 400 V / 3 ph / 50-60 Hz | 400 V / 3 ph / 50-60 Hz | 400 V / 3 ph / 50-60 Hz | 400 V / 3 ph / 50-60 Hz |
| Power | 8 kW max; 4 kW/h average | 12 kW max; 6 kW/h average | 16 kW max; 8 kW/h average | 18 kW max; 9 kW/h average | 21 kW max; 10.5 kW/h average |
| Current draw | 12 A | 19 A | 25 A | 27 A | 32 A |
| Temperature range | 0 to 450°C (32 to 842°F) | 0 to 450°C (32 to 842°F) | 0 to 450°C (32 to 842°F) | 0 to 450°C (32 to 842°F) | 0 to 450°C (32 to 842°F) |
Matching provers and stands
| Component | For T1A / T2A | For T1B / T2B | For T2C | For T2E | For T2F |
|---|---|---|---|---|---|
| Prover (hermetic, with wheels) | BT1A/BT2A: 86 × 85 × 85 cm (33.9 × 33.5 × 33.5 in), 70 kg (154 lb), 3 trays | BT1B/BT2B: 86 × 85 × 115 cm (33.9 × 33.5 × 45.3 in), 80 kg (176 lb), 6 trays | BT2C: 86 × 94 × 128 cm (33.9 × 37 × 50.4 in), 90 kg (198 lb), 6 trays | ||
| Prover supply | 230 V / 1 ph / 50-60 Hz; 1 kW, 0.5 kW/h average; 0 to 90°C (32 to 194°F) | Same | Same | ||
| Tray stand (with wheels) | ST1A/ST2A: 86/70 × 86 × 85 cm (33.9/27.6 × 33.9 × 33.5 in), 26/22 kg (57/49 lb), 6 trays | ST1B/ST2B: 86/70 × 86 × 115 cm (33.9/27.6 × 33.9 × 45.3 in), 28/23 kg (62/51 lb), 6 trays | ST2C: 86/70 × 95 × 128 cm (33.9/27.6 × 37.4 × 50.4 in), 30/25 kg (66/55 lb), 9 trays | ST2E: 86/70 × 130 × 93 cm (33.9/27.6 × 51.2 × 36.6 in), 41/36 kg (90/79 lb), 6 trays | ST2F: 86/70 × 130 × 130 cm (33.9/27.6 × 51.2 × 51.2 in), 45/40 kg (99/88 lb), 9 trays |
| Pans in a deck + prover + stand set (configuration sheet) | Prover 14; stand 14/14 | Prover 14; stand 14/14 | Prover 21; stand 21/21 |
Installation & Requirements
- Power: Requires a 400 V, 3-phase supply. Italforni has not confirmed a US-voltage version or US certification for the TEKNO series; ask us before ordering for a US site.
Sold separately: BT provers, ST tray stands, hood motor kit, AKB motor and steam damper kit with activated carbon filter, CMT2 digital control panel for TEKNO 2, Hyper P-Heating, 4 wheels (13 cm / 5.1 in for stands, 15 cm / 5.9 in for provers), PPD prover feet (8 to 20 cm / 3.1 to 7.9 in).
Ordering & Lead Time
- Factory direct from Italforni in Italy, with a total lead time of 6 to 8 weeks.
- Final sale: not eligible for change-of-mind returns. Full manufacturer warranty and damaged-on-arrival protection still apply.
