The ITALFORNI GM is a spiral dough mixer for bread, pizza and pastry, built in four sizes from the GM8 (5 kg of dough) to the GM38 (35 kg). Every model is offered at 120 V single-phase, and the larger three also come in 400 V three-phase with one or two speeds.
Key Features
- Even dough development: A chain transmission keeps the spiral and bowl turning at the correct ratio, giving homogeneous dough in small and large batches with low running noise.
- Built for daily use: An oil-bath geared motor delivers steady torque through repeated mixing cycles.
- Food-zone stainless steel: The bowl, bowl guard, spiral and dough breaker are AISI 304 (18/8) stainless steel and wipe down quickly between batches.
- Low-voltage controls: 24 V commands at the control panel. Wheels are available as an option.
Specifications
| Specification | GM8 | GM18 | GM25 | GM38 |
|---|---|---|---|---|
| Dough / bowl capacity | 5 kg / 8 L (11 lb / 8.5 qt) (technical table: 6 kg / 7 L) | 17 kg / 21 L (37 lb / 22.2 qt) | 25 kg / 32 L (55 lb / 33.8 qt) | 35 kg / 41 L (77 lb / 43.3 qt) (technical table: 36 kg) |
| External dimensions (H × W × D) | 55 × 29 × 45 cm (21.7 × 11.4 × 17.7 in) | 70 × 40 × 63 cm (27.6 × 15.7 × 24.8 in) | 78 × 44 × 68 cm (30.7 × 17.3 × 26.8 in) | 79.8 × 49.5 × 80 cm (31.4 × 19.5 × 31.5 in) |
| Bowl (diameter × height) | Ø 24 × 16 cm (9.4 × 6.3 in) | Ø 36 × 21 cm (14.2 × 8.3 in) | Ø 40 × 26 cm (15.7 × 10.2 in) | Ø 45 × 26 cm (17.7 × 10.2 in) |
| Weight | 30 kg (66 lb) | 59 kg (130 lb) | 82 kg (181 lb) | 96 kg (212 lb) |
| Motor power | 0.5 Hp (0.37 kW) | 1 Hp (0.75 kW) | 1.5 Hp (1.1 kW) | 2 Hp (1.5 kW) |
| 1-speed power supply | 120 V / 1 ph / 60 Hz | 120 V / 1 ph / 60 Hz or 400 V / 3 ph / 60 Hz | 120 V / 1 ph / 60 Hz or 400 V / 3 ph / 60 Hz | 120 V / 1 ph / 60 Hz or 400 V / 3 ph / 60 Hz |
| 2-speed power supply | Not offered | 400 V / 3 ph / 60 Hz | 400 V / 3 ph / 60 Hz | 400 V / 3 ph / 60 Hz |
| Food-contact parts | AISI 304 stainless steel bowl, guard, spiral, dough breaker | AISI 304 stainless steel bowl, guard, spiral, dough breaker | AISI 304 stainless steel bowl, guard, spiral, dough breaker | AISI 304 stainless steel bowl, guard, spiral, dough breaker |
| Drive | Chain transmission, oil-bath geared motor | Chain transmission, oil-bath geared motor | Chain transmission, oil-bath geared motor | Chain transmission, oil-bath geared motor |
| Controls | 24 V | 24 V | 24 V | 24 V |
| Safety | Built to EU Directive 89/392 and later amendments | Built to EU Directive 89/392 and later amendments | Built to EU Directive 89/392 and later amendments | Built to EU Directive 89/392 and later amendments |
Installation & Requirements
- Power: The 120 V single-phase, 60 Hz versions plug into standard US single-phase service. The three-phase versions are specified at 400 V, 60 Hz; confirm your site voltage with us before choosing a three-phase model.
- Certification: Italforni lists EU Directive 89/392 compliance. US listing (UL, ETL or NSF) has not been confirmed for the GM series.
- Options: Wheels are available on request.
Ordering & Lead Time
- Factory direct from Italforni in Italy, with a total lead time of 6 to 8 weeks.
- Final sale: not eligible for change-of-mind returns. Full manufacturer warranty and damaged-on-arrival protection still apply.
